Bolus Material

BOLX with and without skin and thermoplastic bolus.

BOLX Bolus

BOLX is a flexible, homogeneous bolus material that conforms nicely to the patient anatomical contours. BOLX is made from a tissue-equivalent gel with a density of 1.03 g/cm. It is available in various sizes and thicknesses and can be cut with a pair of scissors to fit the patient’s contours.

  • BOLX can be built up in layers when required to obtain the desired build-up thickness.
  • BOLX bolus is available in an easy to clean version with skin or a skinless version that will stick to the patient's contours and allow stacking.
  • BOLX is calibrated with photon and electrons beams in the energy range of more than 1 MeV.
  • BOLX is 100% latex-free.

Ordering information

Part number Description
153170 BOLX1 bolus 15x15x1,0 cm with skin
153180 BOLX1 bolus 15x15x0,5 cm with skin
153110 BOLX1 bolus 30x30x1,0 cm with skin
153120 BOLX1 bolus 30x30x0,5 cm with skin
153130 BOLX1 bolus 40x40x1,0 cm with skin
153140 BOLX1 bolus 40x40x0,5 cm with skin
153150 BOLX1 bolus 50x50x1,0 cm with skin
153160 BOLX1 bolus 50x50x0,5 cm with skin
153310 BOLX2 bolus 30x30x1,0 cm without skin
153320 BOLX2 bolus 30x30x0,5 cm without skin
153340 BOLX2 40x40x0,5 cm without skin
153330 BOLX2 bolus 40x40x1,0 cm without skin
153350 BOLX2 bolus 50x50x1,0 cm without skin
153360 BOLX2 bolus 50x50x0,5 cm without skin

Thermoplastic Bolus

This low-temperature thermoplastic material is ideal for hard-to-bolus areas and any irregular surfaced anatomical features, softening in water and becoming mouldable. Physics attenuation is comparable to traditional petroleum-based bolus.

Ordering information

Part number Description
CB-2.0-AC Thermoplastic Bolus Pearls 2kg
TB5000/30 Thermoplastic Bolus 0.5 x 30 x 30cm
153210 MacroCast non perfo plate 3,2 mm, 30x30 cm
153220 MacroCast non perfo plate 5 mm, 30x30 cm
